Create a kaleidoscope effect on your web page using the Three.js library. This script transforms images into an interactive kaleidoscope pattern with customizable segments and motion.
Click below to see the setup guide video:
Copy the <script> below and paste it in the <head> or before </body> tag in your project on the pages where you need it. It also works with any newer version of three.js.
<!-- Snippets by The Lazy God • Kaleidoscope -->
<script defer src="https://cdn.jsdelivr.net/npm/[email protected]/three.min.js"></script>
<script defer src="https://cdn.jsdelivr.net/gh/the-lazy-god/[email protected]/tlg-kaleidoscope.min.js"></script>Add the attribute below to any div element you want to contain a kaleidoscope effect.
Note: This element is automatically set to position:relative;. Give it the size you want the kaleidoscope canvas to be using height and width or width and aspect ratio.
Attribute:
- Name:
tlg-kaleidoscope-canvas
Within each canvas container, include one or more image elements with the attribute tlg-kaleidoscope-image. These images will be used in the kaleidoscope pattern. If more than one image element is used a random will be chosen on page load.
Note: Use square images to avoid stretching. Hide the source images with display:none;.
Attribute:
- Name:
tlg-kaleidoscope-image
Set the interaction mode of the kaleidoscope by adding the tlg-kaleidoscope-mode attribute to the container with attribute tlg-kaleidoscope-canvas. Options are "mouse", "static", "loop", and "scroll".
Attribute (Optional):
- Name:
tlg-kaleidoscope-mode - Value:
"static","mouse","loop","scroll"(Default = "static")
Adjust the aspect ratio of the image texture by adding the tlg-kaleidoscope-aspect attribute to each image element with attribute tlg-kaleidoscope-image.
Apply this attribute when using non-square source images.
Specify as a decimal (e.g., "1.78" for a 16/9 aspect ratio) or as a ratio (e.g., "16/9").
Attribute (Optional):
- Name:
tlg-kaleidoscope-aspect - Value:
{number}or{ratio}(e.g., "1.78" or "16/9") (Default = 1)
Control the number of segments in the kaleidoscope by adding the tlg-kaleidoscope-segments attribute to the container with attribute tlg-kaleidoscope-canvas.
Default is 6 segments.
Attribute (Optional):
- Name:
tlg-kaleidoscope-segments - Value:
{number}(Default = 6)
Control the scale of the kaleidoscope texture by adding the tlg-kaleidoscope-scale attribute to the container with attribute tlg-kaleidoscope-canvas.
Default is 1. Larger number will increase the size of each image tile.
Attribute (Optional):
- Name:
tlg-kaleidoscope-scale - Value:
{number}(Default = 1)
Control the intensity of the motion effect with tlg-kaleidoscope-motion attribute to the container with attribute tlg-kaleidoscope-canvas.
Default is 1. Larger number will increase motion intensity.
Attribute (Optional):
- Name:
tlg-kaleidoscope-motion - Value:
{number}(Default = 1)
| Name | Description | Values | Default |
|---|---|---|---|
tlg-kaleidoscope-canvas |
Identifies the container element for the kaleidoscope canvas. Required | None | - |
tlg-kaleidoscope-image |
Marks an image to be used in the kaleidoscope pattern. Required | None | - |
tlg-kaleidoscope-mode |
Sets the animation mode of the kaleidoscope. | "static", "mouse", "loop", "scroll" | "static" |
tlg-kaleidoscope-aspect |
Adjusts the aspect ratio of the image texture. | {Number} or {Ratio} | 1 (square) |
tlg-kaleidoscope-scale |
Sets the scale factor of the kaleidoscope pattern. | {Number} | 1 |
tlg-kaleidoscope-motion |
Controls the intensity of the motion effect based on mouse movement. | {Number} | 1 |
tlg-kaleidoscope-segments |
Determines the number of segments in the kaleidoscope pattern. | {Number} | 6 |
