VSDF

Vulkan SDF Renderer + Hot Reloader

Render an SDF like ShaderToy using Vulkan and hot reload based on frag shader changes. That way you can use your favourite editor / LSP and also utilise git.

Platforms

Supports macOS, Linux, and Windows with native file watcher implementations for each platform.

Mac Dev Setup (with Lunar)

https://vulkan.lunarg.com/sdk/home

Then follow the steps to do sudo ./install_vulkan.py in SDK System Paths section

Example VULKAN_SDK Env Var

VULKAN_SDK $HOME/VulkanSDK/1.4.328.1/macOS

Windows Dev Setup

1. Install vcpkg (if not already installed):

   git clone https://github.com/Microsoft/vcpkg.git
   cd vcpkg
   .\bootstrap-vcpkg.bat

2. Install dependencies using vcpkg (includes Vulkan):

   vcpkg install vulkan:x64-windows glfw3:x64-windows glslang:x64-windows spdlog:x64-windows glm:x64-windows gtest:x64-windows
   vcpkg integrate install

Note: vcpkg provides Vulkan headers and loader, eliminating the need for a separate Vulkan SDK installation.

Build

Linux/macOS

cmake -B build .
cmake --build build
./build/vsdf {filepath}.frag

Windows

cmake -B build -DCMAKE_TOOLCHAIN_FILE="C:/path/to/vcpkg/scripts/buildsystems/vcpkg.cmake" .
cmake --build build --config Release
.\build\Release\vsdf.exe {filepath}.frag

Headless / CI-friendly single-frame run (hide the window and exit after N frames):

./build/vsdf --toy shaders/testtoyshader.frag --frames 1 --headless

Usage

With shader toy shaders (most seem to work)

./build/vsdf --toy path/to/shader.frag

Example test command using a sample shader in this repo

./build/vsdf --toy shaders/testtoyshader.frag

Note: That if you use --toy we will prepend a template in shaders/toytemplate.frag which sets up the push constants like iTime and we will also follow this logic.

if (useToyTemplate) {
    Client = glslang::EShClientOpenGL;
    ClientVersion = glslang::EShTargetOpenGL_450;
} else {
    Client = glslang::EShClientVulkan;
    ClientVersion = glslang::EShTargetVulkan_1_0;
}

Manually create your own vulkan compatible shader

If you don't want any template prepended or you have issues loading that way, I recommend copying shaders/vulktemplate.frag and adjusting it to your liking

• See shaders/vulktemplate.frag to see how push constants are passed in

./build/vsdf path/to/shader.frag

CLI Flags

• --toy Prepend the ShaderToy-compatible template
• --frames <N> Render N frames then exit (helps CI)
• --headless Hide the GLFW window (pair with xvfb-run in CI)
• --log-level <trace|debug|info|warn|error|critical|off> Set spdlog verbosity (default: info)

Test Build

Linux/macOS

cmake -B build -DBUILD_TESTS=ON -DDEBUG=ON
cmake --build build
./build/tests/vsdf_tests
./build/tests/filewatcher/filewatcher_tests

Windows

cmake -B build -DBUILD_TESTS=ON -DCMAKE_BUILD_TYPE=Debug -DCMAKE_TOOLCHAIN_FILE="C:/path/to/vcpkg/scripts/buildsystems/vcpkg.cmake" .
cmake --build build --config Debug
.\build\tests\vsdf_tests\Debug\vsdf_tests.exe
.\build\tests\filewatcher\Debug\filewatcher_tests.exe

Nix Develop Shell

nix develop

Credits:

• https://shadertoy.com
• https://iquilezles.org/
• https://www.youtube.com/playlist?list=PL0JVLUVCkk-l7CWCn3-cdftR0oajugYvd (zeux)
• https://github.com/SaschaWillems/Vulkan

CPP Guidelines

(I should try follow this but haven't gotten through it all yet) https://isocpp.github.io/CppCoreGuidelines/CppCoreGuidelines
